420mm Automatic Diamond Wall Saw Machine Construction Wall Cutting Equipment
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Voltage 380 V Core Components PLC, Bearing, Gearbox, Motor Machinery Test Report Provided Video outgoing-inspection Provided UNIQUE SELLING POINT Fully hydraulic system Cutting Depth 730 mm Rotary Speed 1400 rpm Power(W) 30000 Running Speed 0-2 m/min Weight 220 kg Dimension(L*W*H) 500*520*1100 mm Power Source Hydraulic Max. Working Pressure 210 bar / 21 MPa Saw Head […]
Introduction
| Voltage | 380 V | Core Components | PLC, Bearing, Gearbox, Motor |
| Machinery Test Report | Provided | Video outgoing-inspection | Provided |
| UNIQUE SELLING POINT | Fully hydraulic system | Cutting Depth | 730 mm |
| Rotary Speed | 1400 rpm | Power(W) | 30000 |
| Running Speed | 0-2 m/min | Weight | 220 kg |
| Dimension(L*W*H) | 500*520*1100 mm | Power Source | Hydraulic |
| Max. Working Pressure | 210 bar / 21 MPa | Saw Head Weight | 39 kg |
| Blade diameter | 600-1600 mm | Cutting Material | Reinforced concrete, Brick wall, Stone |
| Packing Size | Customized wooden case | Application for | Concrete wall cutting, Demolition, Renovation |
| Max.oil flow rate | 100L/min | Feature | Wireless Remote Control, Easy Installation |
| Certification | CE ISO | After-sales Service Provided | Online technical support, Spare parts |
Our website currently showcases only a portion of our products. If you have specific requirements or need more detailed product information, please feel free to contact us. Our professional team is ready to provide tailored solutions to help your brand stand out. Whether it’s design adjustments, functional enhancements, or packaging optimization, we are here to meet your expectations. We look forward to collaborating with you to create premium products!
